PN10 PN16 PN25 Ductile Iron Socket Cross With Zinc Layer Bitumen Coating

Ask Lasest Price
Brand Name :	NO
Model Number :	DN80 to DN600
Certification :	NO
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	10 tons per month
Delivery Time :	20-60days

Add to Cart

Product Details
Company Profile

PN10 PN16 PN25 Ductile Iron Socket Cross With Zinc Layer Bitumen Coating

PN10 PN16 PN25 Ductile Iron Socket Cross With Zinc Layer Bitumen Coating

Overview

We offer a comprehensive range of cross fittings in diameter from DN80 to DN600 with a number of jointing options to meet the different requirements of the customer. Extensively used in different industrial units, these fittings are manufactured under the guidance of vendor’s skilled professionals using high grade raw materials in compliance with international standards.

Features

Size ranges DN80 to DN600

Internal coating Cement moatar lining

External caoting Zinc/Zinc alloy, Bitumen, or Epoxy.

Main			Branch			Weight (kg)
DN	e	L	dn	e1	h	T type	K type
80	8.1	85	80	8.1	85	16.6	23.6
100	8.4	85	80	8.1	95	19.7	28.7
100	8.4	95	100	8.4	95	21.5	30.9
125	8.7	85	80	8.1	105	23.5	30.4
		95	100	8.4	110	25.4	33
		110	125	8.7	110	29.4	35.9
150	9.1	85	80	8.1	120	28.7	38.9
		100	100	8.4	120	31.4	41.4
		115	125	8.7	120	34.4	44.4
		130	150	9.1	125	37.4	47.5
200	9.8	90	80	8.1	145	40	50.6
		100	100	8.4	145	42.7	51.8
		115	125	8.7	145	46	55.2
		130	150	9.1	150	49.4	58.7
		160	200	9.8	155	64.7	66
250	10.5	90	80	8.1	170	53.6	57.3
		100	100	8.4	170	57	63.9
		115	125	8.7	175	61.3	65.5
		130	150	9.1	175	68.1	75.2
		160	200	9.8	180	74.5	81.2
		190	250	10.5	190	85.5	89.9
300	11.2	95	80	8.1	195	79.2	87.2
		105	100	8.4	195	81.5	90.3
		120	125	8.7	200	87	95.6
		130	150	9.1	200	89.6	103.5
		160	200	9.8	205	100.7	110.5
		190	250	10.5	210	112.2	122.8
		220	300	11.2	220	130.2	139.3
350	11.9	95	80	8.1	220	84.8	99.3
		105	100	8.4	220	89.6	106.7
		130	150	9.1	225	106	123.5
		150	200	9.8	230	113	130.0
		180	250	10.5	235	129.2	145.3
		210	300	112	240	141.1	162.7
		250	350	11.9	250	154	175
400	12.6	95	80	8.1	240	101.5	116
		105	100	8.4	245	109.6	126.7
		120	125	8.7	250	119	136.7
		135	150	9.1	250	128.9	146.7
		165	200	9.8	255	136	153.3
		190	250	10.5	260	154.7	171
		220	300	11.2	270	168	189.3
		250	350	11.9	270	182.7	202.7
		280	400	12.6	280	200	221
450	13.3	95	80	8.1	270	134.7	136.7
		105	100	8.4	270	141.3	154.7
		120	125	8.7	270	148	161.3
		135	150	9.1	280	154.7	168
		165	200	9.8	280	169.3	182.7
		195	250	10.5	290	184	196
		220	300	11.2	290	198.7	217
		250	350	11.9	300	214.7	233
		280	400	12.6	300	234.7	248
		310	450	13.3	310	248	264
500	14	95	80	8.1	290	146.7	155.7
		110	100	8.4	295	153.3	164
		120	125	8.7	300	168	178.6
		135	150	9.1	300	182.7	193
		165	200	9.8	310	188	198.7
		195	250	10.5	310	214.7	224
		225	300	11.2	320	232	247
		255	350	11.9	320	249.3	264
		280	400	12.6	330	265.3	280
		310	450	13.3	335	285.3	299
		340	500	14.0	340	312	322
600	15.4	100	80	8.1	340	220	220
		110	100	8.4	345	225.3	224
		125	125	8.7	350	236	234.7
		140	150	9.1	350	246.7	245.3
		170	200	9.8	360	250.7	249
		200	250	10.5	360	286	284
		225	300	11.2	370	308	310.7
		255	350	11.9	370	328	330
		285	400	12.6	380	344	346.7
		315	450	13.3	385	373.3	374.7
		345	500	14.0	390	394.7	394.7
		400	600	15.4	400	457	450

Mechanical Properties

Minimum elongation : DI Fittings: ≥5%

Minimum ultimate Tensile Strength: ≥420
HWB Hardness: ≤230
