DN600 to DN1200 Ductile iron fittings Zinc spaying Double flange reducer

Ask Lasest Price
Model Number :	DN80- DN2600
Payment Terms :	L/C, D/A, D/P, T/T
Delivery Time :	20-60 days
Brand Name :	NO
Certification :	NO

Add to Cart

Product Details
Company Profile

DN600 to DN1200 Ductile iron fittings Zinc spaying Double flange reducer

DN100 to DN2600 Ductile iron fittings Zinc spaying Double flange reducer

Overview

Our range of ductile iron fittings offer durability and strength for long-term performance across a range of water, sewage, waste water and slurry applications. Our ductile iron fittings are manufactured to ISO2531, EN 545 for premium quality and superior long-tern reliability and performance.

We offer wide range of standard fitting flanges in accordance with ISO2531. Our products range from DN100 to DN2600,nominal pressure rating of PN10,PN16&PN25.

Properties & Dimensions

size range DN100 to DN2600

Flange fittings Class PN10, Class PN16 & Class PN25

The size and weight of Double flange reducer

DN	e1	dn	e2	L	Weight(kg)
DN	e1	dn	e2	L	PN10	PN16	PN25
600	13.2	80	7.0	1050	122.4	147.4	159.8
		100	7.2	1050	125.6	150.6	163.5
		150	7.8	1000	130.1	155.1	168.5
		250	9.0	900	139.5	164.1	180.2
		300	9.6	800	138.3	163.0	180.6
		350	10.2	750	140.4	168.2	188.5
		400	10.8	700	142.9	174.4	196.0
		450	11.4	650	143.8	178.1	200.9
		500	12.0	600	149.0	190.0	216 0
700	14.4	200	8.4	1100	181.1	195.3	229,6
		25Q	9.0	1050	186.8	200.6	236.7
		300	9.6	1000	192,4	206.2	243.9
		350	10.2	900	188.3	205.2	245.6
		400	10.8	800	183.5	204.1	229.6
		450	11.4	750	184.7	208.1	251.0
		500	12.0	700	187.7	216.2	259.1
		600	13.2	600	195.0	236.0	238.0
800	15.6	400	10.8	1030	260.8	285.0	340.2
		450	11.4	900	247.8	274.8	331.2
		500	120.0	800	241.2	273.3	329.7
		600	13.2	700	245.7	288.4	346.8
		700	14.4	600	250.0	285.0	374.0
900	16.8	400	10.8	1100	311.5	339.6	404.8
		450	11.4	1050	314.1	345.0	411.4
		500	12.0	1000	318.8	354.6	421.2
		600	13.2	800	300.2	346.8	415.2
		700	14.4	700	301.9	337.6	426.1
		800	15.6	600	308.0	352.0	468.0
1000	18	600	13.2	1000	398.6	461.3	546.3
		700	14.4	800	371.6	423.4	528.5
		800	15.6	700	376.2	431.6	550.2
		900	16.8	600	373.0	438.0	585.0
1100	19.2	600	13.2	1100	479.1	542.5	638.9
		700	14.4	1000	483.9	536.4	652.9
		800	15.6	800	454.4	510.5	640.5
		900	16.8	700	448.1	508.1	648.1
		1000	18.0	600	444.4	520. 5	677.1
1200	20.4	600	13.2	1150	555.2	638.5	741.6
		700	14.4	1100	578.0	650.4	773.6
		800	15.6	1000	587.2	663.2	799.9
		900	16.8	800	539.9	619.8	766.5
		1000	16.0	700	536.7	632.7	796.0
		1100	19.2	600	527.6	624.3	799.0

Double flange reducer.pdf
