Small Diameter 3 Inch Seamless Cs Pipe Astm A53 Grade B SCH40 Thickness

Ask Lasest Price
Brand Name :	NO
Model Number :	2inch -8inch
Certification :	API, ISO
Price :	Negotiation
Payment Terms :	L/C, T/T
Delivery Time :	30-60 days

Add to Cart

Product Details
Company Profile

Small Diameter 3 Inch Seamless Cs Pipe Astm A53 Grade B SCH40 Thickness

Small Diameter 3 Inch Seamless Cs Pipe Astm A53 Grade B SCH40 Thickness

Description of Carbon steel seamless pipe API 5L Grade B of 3 inch seamless steel riser pipe for well

Size:2inch-8inch

Grade:API 5L Grade B

Standard: ASTM A 53 GRADE B OR API 5L GRADE B

Thicknee:SCH40

Length tolerance:-0/+100mm

Condition: Seamless steel pipe,

Length of coupling: min 200mm

Taper:3/4 inch per foot

Technical data:

Size	WT (SCH40)	Length End of pipe to Hand tight plane L₁ (mm)	Length Effective Thread L₂ (mm)	Total length End of pipe to vanish point L₄ (mm)	Number per inch	Minimum length, full Crest Threads from end of pipe L_C (mm)	End of pipe to Center of Coupling, Power-Tight Make-Up J (mm)	Length N_L (mm)
2”(60.33)	3.91mm	24.86	36.9	42	10	19	12.7	203
3”(88.9)	5.49mm	42.5	48	58.75	8	35.9	12.7	203
4”(114.3)	6.02mm	48.8	68.96	76.2	8	47.625	12.7	203
5”(141.3)	6.55mm	61.5	81.66	88.9	8	60.325	12.7	203
6”(168.28)	7.11mm	70.45	90	97.6	8	69.025	12.7	220

Factory test and other terms:

1. Hydrostatic or Nondestructive Electric Test

2. Heat Treatment: according to Standard
3. Surface Condition:According to Standard.
4. Grain Size:According to standard
5. Sampling:flattening,flaring,grain size,Marking

6. we provide bevel end,plastic cap, varnish coating, oiled or black painted to prevent rustand other packing

service.

Small Diameter 3 Inch Seamless Cs Pipe Astm A53 Grade B SCH40 Thickness
